製品詳細
起源の場所: 陶磁器
ブランド名: HUAKE
証明: CE SGS
モデル番号: Y81-200
支払いと送料の条件
最小注文数量: 1セット
価格: 8000-20000 USD
パッケージの詳細: 輸出価値があるパッケージ
受渡し時間: 35-40幾日
支払条件: L/C、T/T、D/P、ウェスタン・ユニオン、Paypal、お金のグラム
供給の能力: 1年ごとの200PCS
モデルいいえ。: |
Y81-200 |
港: |
上海、中国 |
輸送のパッケージ: |
裸のパッキング、直接負荷容器 |
指定: |
Y81 |
商標: |
huake |
起源: |
江蘇中国 |
モデルいいえ。: |
Y81-200 |
港: |
上海、中国 |
輸送のパッケージ: |
裸のパッキング、直接負荷容器 |
指定: |
Y81 |
商標: |
huake |
起源: |
江蘇中国 |
scrap steel recycling SGS Safe ferrous non -ferrous Scrap Steel Recycling Baler
|
81 Series Hydraulic scrap metal baler sepcs |
|||||
| Type | Nominal Force | Power | Feed Box Size | Bale Size | Productivity |
| ( KN ) | ( KW ) | ( mm ) | (mm ) | ( kg/h ) | |
| Y81-1250 | 1250 | 15 | 1200 × 700 × 600 | 300 × 300 | 800-1500 |
| Y81Q-1350 | 1350 | 22 | 1400 × 600 × 600 | 600 × 240 | 1500-2200 |
| Y81-1600A | 1600 | 22 | 1600 × 1000 × 700 | 350 × 350 | 2000-3000 |
| Y81-1600B | 1600 | 22 | 1600 × 1200 × 800 | 400 × 400 | 2000-3000 |
| Y81-2000A | 2000 | 30 | 1600 × 1200 × 800 | 400 × 400 | 2000-3000 |
| Y81-2000B | 2000 | 37 | 1800 × 1400 × 900 | 450 × 450 | 2500-3500 |
| Y81-2500A | 2500 | 44 | 1800 × 1400 × 900 | 450 × 450 | 3000-5000 |
| Y81-2500B | 2500 | 44 | 2000 × 1400 × 900 | 500 × 500 | 3000-5000 |
| Y81-2500C | 2500 | 60 | 2000 × 1750 × 1000 | 500 × 500 | 3500-5000 |
| Y81-3150A | 3150 | 60 | 2000 × 1400 × 1000 | 500 × 500 | 3500-5000 |
| Y81-3150B | 3150 | 60/66 | 2000 × 1750 × 1200 | 500 × 500 | 3500-5000 |
| Y81-3150C | 3150 | 90 | 2600 × 2000 × 1200 | 550 × 550 | 4000-7000 |
| Y81-4000A | 4000 | 66 | 2000 × 1600 × 1100 | 550 × 550 | 4000-7000 |
| Y81-4000B | 4000 | 110 | 2600 × 1750 × 1200 | 550 × 550 | 5000-8000 |
| Y81-4000C | 4000 | 90 | 3000 × 2000 × 1200 | 600 × 600 | 6000-8000 |
| Y81-6000 | 6000 | 135 | 5000 × 2000 × 1200 | 700 × 700 | 8000-10000 |
Features:
A) Hydraulic drive, manual valve operation or PLC control...
B) Bale-discharging: "turn-out", "push-out", "forward-out" & manual discharging.
C) Options for different force, press box size, bale shape & size
D) Electrical motor, diesel engine or generator for power.
Applications:
Y81 series of hydraulic scrap balers are applied in steel mills, recycling plants, ferrous & non
-ferrous smelting industry to press scrap metal (steel, copper, aluminum, stainless steel, discarded automobiles, etc)
Into acceptable furnace charges in shape of cuboids, cylinders & octagons.
Baler can deal with the following martials, pls feel free to check and contact us!
Features
1. Driven by hydraulic system, this turn out baler is highlighted by resoanble design, compact structure, small volume, light weight, small inetia of movement, low noise, stable traveling performance, flexible operation and so on.
2. Under the integrated hydraulic and electrical control, it is easy for operation and maintance.
3. With wide applicable range, this product can work as the processing equipment in scrap metal recycling unit. It is also suitable for processing the furnace charge in the foundry of factory. The equipment offers powerful adaptabiity for the working conditions.
4. Our turn out baler performs with low energy consumption, easy installation, secure operation, high working efficiency, low price and other merits.
CE SGS safe Scrap Steel Recycling Baler
